The reinforcing steel bars are used in construction sector to reinforce concrete structures. The ribs ensure perfect adhesion with the concrete. They are also used for making chain links and welded meshes. The size of reinforcing steel bars range from 8 to 32 mm for a length from 6 m to 18 m.
The reinforcing steel bars (rebars) are used in reinforced concrete constructions to strengthen the concrete structures under tension. The ribs on the steel bars provide perfect adherence with concrete, allowing the concrete and the rebars to move together.The bars can be cut and bent to the desired size..
Reinforcing bars production range
-
Size
Rebars: From 8 mm to 32 mm
Rebar in coils: 8 mm to 16 mm
-
Length
Rebars: From 6 meters to 18 meters
-
Bundle weight
Rebars: from 1000 kg to 3000 kg
Rebars in coils: about 2000 kg
Reinforcing bars production standards and steel qualities
Standard | Steel grades |
---|---|
NA ISO 6935-2 NA 8634 | RB500BWR |
DIN 488:2009 | B500B |
NEN 6008, BRL 0501 | B500B |
NBN A 24 301-304 | BE500S |
ST 009-2011 | B500C |
BDS 9252 | B500C |
CSA - G30.18-9 | GR500W |
CSA - G30.18-9 | GR400W |
ASTM A615 | GR 40 |
ASTM A615 | GR 60 |
ASTM A615 | GR 75 |
ASTM A 706 | GR 60 |
Specifications and catalogue
