Hot-dip Galvanized Products

These products are produced by hot-dip galvanizing of both surfaces of the cold-rolled flat steels or pickled hot-rolled flat steels.

Production at requested surface quality, with chromate (Cr⁺³) and / or oil coating, organic film coated is possible based on customer preference.

Production Range

Product Type	Form of Products
Product Type	Coil		Trimmed Edge				Cut to Length		Trimmed Edge and Cut to Length
Continuous Galvanized	GCR		GCRK				GCRC		GCRKC
Steel Type	Low Carbon Steel		Ultra Low Carbon Steel		Medium Strength		High Strength		DP600 DP780		BH
Hot Dip Galvanized Steels	DX51D+Z DX52D+Z DX53D+Z		DX54D+Z DX56D+Z DX57D+Z		S220GD+Z S250GD+Z S280GD+Z S320GD+Z		HX260LAD HX500LAD		HCT590X+Z HCT780X+Z		HX180BD+Z HX300BD+Z
Thickness	Width (mm)		Width (mm)		Width (mm)		Width (mm)		Width (mm)		Width (mm)
Thickness	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max
0,30 - 0,43	730	1550	730	1650	730	1650	1000	1650	1100	1300	1100	1300
0,44 - 0,49	730	1650	730	1650	730	1650	900	1650	1100	1300	1100	1650
0,50 - 0,59	730	1650	730	1650	730	1650	900	1650	1100	1650	1100	1650
0,60 - 0,69	730	1650	730	1650	730	1650	730	1650	1100	1650	1100	1650
0,70 - 0,79	730	1650	730	1650	730	1650	730	1650	1100	1650	1100	1650
0,80 - 0,89	730	1650	730	1650	730	1650	730	1650	1100	1650	1100	1650
0,90 - 0,99	730	1650	730	1650	730	1650	900	1650	900	1650	900	1650
1,00 - 1,20	730	1650	730	1650	730	1650	900	1650	900	1650	900	1650
1,50 - 2,00	900	1650	900	1650	900	1650	900	1650	900	1300	900	1650
2,00 - 3,00	900	1300	900	1650	900	1650	900	1650	900	1300	900	1300
REMARKS	(GI) Galvanized Iron / Hot Dip Galvanized Steel - (GA) Galvannealed - Non-chromium passivized product - Oiled product - Self lubricating products

Subject:

Thicknesses below 0,30 mm and thicknesses between 2,00-3,00 mm are subject to negotiation.
The Customer Technical Services should be contacted for technical questions not specified in the table.
The Customer Technical Services should be contacted for DP 600 and DP 780 grades delivery conditions.
